SG-80KVA three-phase isolation transformer

65+ Years of Experience

SG-80KVA three-phase isolation transformer

Capacity 80kVA, primary side voltage 380V AC, secondary side voltage 220V AC, optional coil material (aluminum and copper). Lower heat emissions and lower operating costs make this transformer ideal for a wide range of a wide range of applications.

Rated voltage:
Rated capacity:
Application scenarios:

What is a SG-80KVA three-phase isolation transformer？

3 phase isolation transformers are 3 phase transformers with isolated primary and secondary windings. As a result, the power input will be separated from the power output. It can safeguard sensitive equipment.

The feature of SG-80KVA three-phase isolation transformer

Establishing a new neutral-grounding in the isolation transformer can relieve the common mode interference and other neutrals in the power grid.
The isolation transformer converts the three-wire △ wiring into a four-wire Yo system,
and the shielding further eliminates the high-frequency pulse interference coupled by the transformer and noise.

The features and advantages of SG-80KVA three-phase isolation transformer

1 High isolation

2 Good performance of N-G

3 High common mode interference suppression

4 Convert △ to Y

5 Voltage taps are easy to convert

6 Designed according to user's special performance requirements

The technical index of SG-80KVA three-phase isolation transformer

Basics	Model	SG-80KVA
	Phase	3 phase
	Capacity	80 kVA
	Weight of Copper Wire Transformer	250Kg
	Weight of Copper Wire Transformer	250Kg
	Dimension of Copper Wire Transformer	800550800
	Dimension of Copper Wire Transformer	800550800
Technical Parameters	Primary Voltage	380V (Optional: 190V/ 208V/ 220V/ 230V/ 240V/ 380V)
	Secondary Voltage	220V (Optional: 190V/ 208V/ 220V)
	Frequency	50Hz / 60 Hz
	Insulation Grade	H level
	Wiring Mode	Dyn11
	Voltage Convert	Three phase to three phase
	Winding Material	Aluminium/Copper wire (Optional)
	Work Efficiency	≥95%
	Insulation Resistance	≥50 MΩ
	Electrical Strength	2500V AC/1 min
	Noise	<35-65dB (1 meter)
	Cooling Mode	Dry type air cooling
	Overload Capacity	Allow more than 1.2 times rated load to work for up to 4 hours
	Enclosure Protection Grade	IP54/IP20
	Certificate	CE, ISO
Working Environment	Temperature	‘-15℃~+45℃
	Humidity	≤90%RH, without condensation
	Altitude	<5000m, non corrosive gas and conductive dust
